Frame
FORM Alloy | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4TM Adjustable Geometry | 2 Position Axle | 140mm Travel | FORM Alloy Rear Triangle
Fork
RockShox 35 Gold RL 150mm | 27.5 = 37mm Offset | 29 = 42mm Offset
Headset
FSA ZS56|66 Reach Adjust| 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Rear Shock
RockShox Deluxe Select RT | Sealed Bearing Eyelet | 20x8mm F Hardware | XS – SM = 190x45mm | MD – LG – XL = 210x52.5mm | Size- Specific tune in FAQ
Rims/Wheels
WTB ST i30 TCS 2.0 Tubeless | 28H
Hubs
F: Shimano TC500 | 15x110m | 28H. R: Shimano TC500 Boost 148mm | 28H
Spokes
2.0 Stainless
Tires
Maxxis Dissector 2.4 WT EXO Tubeless Ready
Crankset
Shimano Deore | 32T | 24mm Spindle | Crankarm Length: XS – SM = 165mm | MD – XL = 170mm
Bottom Bracket
Shimano SM-BBMT500
Chain
Shimano M6100
Rear Derailleur
Shimano Deore 12spd
Shifters
Shimano Deore 12spd
Handlebars
Rocky Mountain AM | 780mm Width | 25mm Rise | 9°
Backsweep | 5° Upsweep | 31.8 Clamp
Tape/Grips
ODI Elite Pro Lock On
Stem
Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm
Brakes
Shimano MT4120 4 Piston | Resin Pads
Saddle
WTB Volt 142
Seat Post
X Fusion Manic Composite 30.9mm | XS = 125mm | SM = 150mm | MD = 170mm | LG – XL = 200mm
