Frame FORM™ Alloy | Full Sealed Cartridge Bearings | BSA Threaded BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 160mm Travel
Fork ox 38 Float EVOL GRIP Performance Series 170mm | 27.5 = 37mm Offset | 29 = 44mm Offset
Headset FSA ZS56|66 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Rear Shock Fox Float X Performance | Sealed Bearing Eyelet | 40x10mm F Hardware | SM = 210x55mm | MD – LG – XL = 230x60mm
Rims/Wheels WTB ST i30 TCS 2.0 Tubeless | 32H
Hubs F: Rocky Mountain SL Sealed Boost 15mm | R: Shimano XT Boost 148mm
Spokes DT Swiss Competition 2.0/1.8/2.0
Tires F: Maxxis Assegai 2.5 WT 3C MaxxGrip EXO+ Tubeless Ready | R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready
Crankset Race Face Aeffect Cinch | 32T | 24mm Spindle | SM = 165mm | MD – XL = 170mm
Bottom Bracket Shimano Threaded BBMT501-B
Chain Shimano M6100
Rear Derailleur Shimano XT
Cassette/Rear Cogs Shimano Deore 10-51T 12spd
Shifters Shimano SLX
Handlebars Rocky Mountain AM | 780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
Tape/Grips ODI Elite Pro Lock On
Stem Rocky Mountain 35 AM | 5° Rise | All Sizes = 40mm
Brakes Shimano SLX Trail 4 Piston | Metal Pads | Shimano RT64 203mm
Pedals Not Included
Saddle WTB Volt Race 142
Seat Post X Fusion Manic Alloy 30.9mm | Shimano MT500 Remote | SM = 150mm | MD = 170mm | LG – XL = 200mm
