Frame
FORMâ„¢ Alloy | Press Fit BB |Integrated Display | Internal Cable Routing | 197mm Rear Spacing | Tapered Zerostack Headtube | Dropper Post Compatible | Rear Triangle
Drive System
Dyname 4.0 Mountain Bike Drive | 700W Max Power | 250W Nominal Power | 108Nm | Rocky Mountain Micro Remote | Low RPM – High Efficiency class 1 eMTB System | Designed in Canada
Battery
720 Wh Removable Integrated Li-Ion | 100% Charged in 3:55 (4A) / 7:35 (2A) | 80% Charged in 2:55 (4A) / 6:05 (2A)
Remote
Rocky Mountain Micro Remote
Display
Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist
Level | Trip | Speed | Cadence | Top Tube Integration
Charger
Rocky Mountain Powerplay Charger V1| 2A | 48V | Higo Deep Socket Connector | Overtimepack Compatible (Dyname 4)
Fork
Rocky Mountain Carbon Fat
Headset
FSA Orbit NO.57E ZS44|56 | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Stem
Rocky Mountain 35 AM | 5° Rise | All Sizes = 40m
Handlebars
Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
Grips
Rocky Mountain Lock On Foam
Brakes
Sram Level 2 Piston | Resin Pads
Shifters
MicroShift Advent X 10spd E
Rear Derailleur
MicroShift Advent X 10spd With Clutch
Crankset
Race Face Ride Cinch 34T | 24mm Spindle | Crank Length: SM-MD = 170mm | LG-XL = 175MM
Bottom Bracket
Race Face BB124 24mm
Cassette
MicroShift CS-EH104 11-48T
Chain
KMC X10-1
Front Hub
Rocky Mountain Sealed 150 x 15mm
Rear Hub
DT Swiss 350 197mm | 36T Star-Ratchet
Spokes
DT Swiss Champion 2.0
Rims
WTB KOM Light i76 | TCS Tubeless | 32 H / Tubeless Ready – Tape / Valves Incl
Tires
F: WTB Bailiff TCS Light/High Grip 120TPI 27.5 x 4.5 // R: WTB Bailiff TCS Light/High Grip 120TPI 27.5 x 4.5
Saddle
WTB Volt 142
* Subject to change without notice.
